Operating
PLC connection to vehicle
This function is only visible to and configurable by
the Customer service user. If the PLC connection is
disabled, no more data is transferred to the vehicle
via the cable.
This mode is required during certain measurements,
for example.
When data transfer is active, charging uses the
charging protocol (high-level communication) as
standard.
When data transfer is disabled, charging is based on
electrical parameters (pulse width modulation).
Adding the energy manager
For charging control to be assumed by the energy
manager, first the charger (EEBus device) and the
energy manager must be connected to one another.
Connection can be established both in the Web Ap-
plication of the energy manager and the Web Appli-
cation of the charger (or directly on the charger).
Establishing a connection to the charger on the en-
ergy manager
g The procedure for establishing the connection to
the charger is described in the chapter "Adding an
EEBus device" in the web application instructions for
the Porsche Home Energy Manager.
76
Establishing a connection to the energy manager
on the charger
b The charger and energy manager are in the same
network.
1. In the Web Application of the charger, navigate
to Connections e Energy manager.
�� The energy manager is shown in the Availa-
ble energy managers list.
2. Select and expand the energy manager.
3. Select Pair device.
�� The connection is checked.
4. In the Establish connection dialogue box, check
the identity of the energy manager once more
using the ID number (SKI), then select Connect.
�� The energy manager is successfully connec-
ted and the status Energy manager connec-
ted is displayed.
The energy manager settings (e.g. informa-
tion on the charging current, overload pro-
tection, optimised charging and tariff set-
tings) are adopted by the charger.
Disconnecting from the energy manager:
1. In the web application of the charger, navigate to
Connections e Energy manager.
�� The connected energy manager is shown
with the status Energy manager connected.
2. Select Disconnect.
�� The connection between the energy man-
ager and the charger is broken.
Pairing user profiles
Information
To transfer data to your Porsche ID account, the de-
vice must be connected to the Internet.
In your Porsche ID account, you can also retrieve
information on charging processes. To do this, the
charger must be paired with a Porsche ID.
1. Select the Link user profile button.
�� The Link user profile dialogue box opens.
2. Depending on whether there is an Internet con-
nection, select the following option (see "Inter-
net connection options").
3. On the Porsche ID account website, enter your
login data (Porsche ID, password).
Internet connection options
Option Explanation
b Web Application connected to
To My Por-
sche
the Internet.
e
You will be redirected straight
to your Porsche ID account.
b Web Application not connec-
More op-
tions
ted to the Internet.
e
If your mobile device has
an Internet connection, either
scan the displayed QR code or
enter the displayed URL man-
ually in your browser.
