Mechanical data for basic wall mount
9Y0.971.675...
Basic wall mount dimensions
Weight of basic wall mount
Cable guide dimensions
Weight of cable guide
Connector fastener dimensions
Weight of connector fastener
Weight of complete basic wall mount
A stands for impending design changes and can be
1)
any letter.
Mechanical data for charging dock
9Y0.971.675...
Charging dock dimensions
Weight of charging dock
Ambient and storage conditions
9Y0.971.675...
Ambient temperature
Air humidity
Altitude
1) A stands for impending design changes and can be
any letter.
BE
MCC72E2 A
1)
385 mm x 135 mm x 65 mm (length x width x height)
approx. 0.45 kg
127 mm x 115 mm x 139 mm (length x width x height)
approx. 0.42 kg.
136 mm x 50 mm x 173 mm (length x width x height)
approx. 0.14 kg.
approx. 1 kg
BE
MCC72E2 A
1)
373 mm x 642 mm x 232 mm (width x height x depth)
approx. 9.7 kg
BE
MCC72E2 A
1)
–30 °C to +50 °C
5% – 95% non-condensing
max. 5,000 m above sea level
BG
MCC11E3 A
1)
BG
MCC11E3 A
1)
BG
MCC11E3 A
1)
Technical Data
BJ
MCC22E3 A
1)
BJ
MCC22E3 A
1)
BJ
MCC22E3 A
1)
87
