InTRoDUCTIon

The purpose of this manual is to furnish the
owner and operator of this equipment with a set
of practical and safe instructions for the use and
maintenance of the wheel aligner.
Follow all the instructions carefully and your
equipment will assist you in your work and give
lasting, efficient service in keeping with CORGHI
traditions.
The following points define the levels of danger
regarding the equipment, associated with the
warning captions found in this manual:
DANGER
Immediate dangers which cause serious injury
or death.
WARNING
Dangers or unsafe procedures that can cause
serious injury or death.
ATTENTION
Dangers or unsafe procedures that can cause
minor injuries or damage to property.
Read these instructions carefully before powering
up the equipment. Conserve this manual and all
illustrative material supplied with the equipment
in a folder near the equipment where it is readily
accessible for consultation by the operators.
The technical documentation supplied is consid-
ered an integral part of the equipment; in the
event of sale all relative documentation must
remain with the system.
The manual is only to be considered valid for the
equipment of the model and with the serial number
indicated on the nameplate applied to it.
WARNING
Adhere to the contents of this manual: the
manufacturer declines all liability in the case
of uses of the equipment not specifically de-
scribed in this manual.
NOTE
Some of the illustrations in this manual have been
taken from photographs of prototypes: standard
production systems may differ in some details.
These instructions are intended for people with
a fair level of mechanical knowledge. We have
therefore not considered it necessary to describe
every single operation, such as the procedure for
loosening or tightening fixing devices, etc. Never
carry out operations which exceed your level
of operating skill, or of which you do not have
experience. If assistance is required, contact an
authorised service centre.
Operator's Manual EXACT 7000
TRAnsPoRT, sToRAGE
AnD HAnDLInG

Equipment transport conditions

The aligner must be shipped in its original
packing and stowed in the position indicated
on the outside.
Ambient conditions for storage of
the equipment
Relative humidity 20% ÷ 80%
Temperature range -10° ÷ +60°C.
WARNING
To avoid damage, never place other items on
top of the packaging.

Handling

To move the packing, insert the tines of a fork-lift
truck into the slots on the base (pallet) (fig.1).
Remove the three fixing brackets (A fig.1)
To move the equipment, use the wheels of the
aligner; to lift it, insert the tines of a fork-lift truck
under the lower base of the cabinet, keeping
them close to the wheels of the aligner (fig.2).
Take care not to break the door.
ATTENTION
Keep the original packaging for use if the
equipment has to be transported again in
the future.
The warranties on the monitor, personal com-
puter and printer are no longer valid if the
original packaging is missing.
