7.

MACHINE DISPOSAL

If the decision is taken not to use this machine any longer, we advise you to make it inactive. Any parts of the
machine which may be of risk to safety should be put out of action.
Classify the product according to its class of disposal.
Scrap product as scrap metal and take to a centre specialised in scrap metal disposal.
If considered a special waste product, dismantle and divide into uniform parts, then dispose of according to law.
INSTRUCTIONS FOR THE CORRECT MANAGEMENT OF WASTE FROM ELECTRIC AND ELECTRONIC
EQUIPMENT (WEEE) ACCORDING TO LEGISLATIVE DECREE 151/05 AND 2002/96/EEC AND 2003/108/EEC
DIRECTIVES.
•
•
•
•
it, and cause damage to human health, flora and fauna.
•
National laws provide for sanctions against those responsible for illegal disposal or abandonment of waste from
electric and electronic equipment.
8.

TROUBLESHOOTING

Possible troubles which might occur to the tyre-changer are listed below. Ravaglioli S.p.A. disclaims all
responsibility for damages to people, animals or objects due to improper operation by non-unauthorised
personnel. In case of trouble, call Ravaglioli Technical Service Department for instructions on how to
service and/or adjust the machine in full safety to avoid any risk of damage to people, animals or objects.
In an emergency and before maintenance, set the main switch to "0" and lock it in this position.
TROUBLE
Machine will not work when
main switch is turned on.
Pump motor does not work
but chucking table motor
works.
When main switch is turned
on, the chucking table does
not turn whereas the pump
motor works.
Oil leakage.
Power drop during chucking
table rotation.
Noisy control unit.
No pressure in the hydraulic
system .
Irregular movements.
42
WEEE may not be disposed of as urban waste.
These kinds of waste must be collected separately and taken to dedicated collection and
recycling centres, according to OEM instructions and abiding by national laws.
The above symbol on the product means that anyone wishing to dispose of the waste must
follow the above-mentioned instructions.
Any incorrect management of the waste or its parts or its abandonment outside dedicated
areas could contaminate the environment, owing to the dangerous substances contained in
CONTACT AUTHORISED TECHNICAL SERVICE –
----> Do not try and service alone.
CAUSE
No voltage.
a)
Protection
b)
blown.
a) Hydraulic control unit damaged.
a) Gearbox change-over switch
damaged.
a) Fittings not correctly fixed.
Hoses defective.
b)
a) Timing belt too loose.
a) Joint damaged.
a) Pump damaged.
a) Low oil.
a)
fuses or motors
b)
c)
a) Call Technical Service Dept.
a) Call Technical Service Dept.
a)
b)
a) Tension up the belt.
a) Replace joint.
a) Replace pump.
a) Top up oil level.
1465-M001-3
REMEDY
Check that plug is
connected and power mains
operation.
Check that machine rating is
compatible with mains.
Check efficiency, connections and
fuses (remove the
guard).
Tighten the fittings.
Replace hoses.
properly
protection
