Macros Window Create Page - Blackmagic Design ATEM Mini Manual De Instalación Y Funcionamiento

To compile small macros into a large macro:
1 Start recording a new macro, then while the macro is recording, click on the 'run'
button to enter the run page.
2 Select 'recall and run' to automatically run macros at the push or click of a button,
or deselect to load a macro and play it manually.
3 Run your sequence of small macros, with pauses between each one to cover the
duration of each small macro, until you've completed the large macro.
4 Stop recording. You now have a complex, powerful large macro built from small macros
you can easily change later if you need to.
There is no limit to the amount of actions you can perform. You can easily build complex
transitions, create unique repeatable effects using keyers, or set up frequently used Blackmagic
Studio Camera settings, graphic overlays and DVEs so you don't have to reconstruct them
every time you start a new program. Macros are fun and will save you a lot of time!

Macros Window Create Page

Create macro button:
Click this button to open the create
macro popup window. From here
you can name a new macro to be
recorded, write a description of your
macro in the notes section, and click
record to start recording your macro.
Arrow buttons and page Icons:
To access or record more than 20 macros, simply click on the
right arrow at the bottom corner of the macros window to open
a new page of macros. To move to the previous page of macros,
click on the left arrow. You can see which page of macros you
are viewing by observing the page icons between the arrows.
Edit macro button:
First select the macro you
want to edit, then click
on the edit macro button
to edit the name and
description of the macro.
Delete macro button:
Select the macro you want
to delete, then click on the
delete macro button to
delete the selected macro.
Macro buttons:
After recording a macro
to a selected macro slot,
your macro will appear as
a macro button. 20 macro
buttons can be displayed
on one page. If a macro is
unnamed when recording,
the number of the selected
macro slot will be used.
Status window:
This window provides helpful prompts
and status messages to help you
get started recording and running your
macros. When a macro is selected, it also
displays any notes you have included.
Using Macros 47
