HyperDeck Settings

HyperDeck settings
You can connect up to 4 Blackmagic HyperDeck Studio disk recorders to a network via
Ethernet and control them using ATEM Software Control. When connecting HyperDecks, use
these settings to configure the IP Address, select the inputs your HyperDecks are connected
to, turn the auto roll feature for each deck on or off, and set their frame offset settings so they
can switch cleanly.
Status indicators appear above and below each deck so you can easily see if they are
successfully connected and if their remote buttons are active.
For detailed information on setting up Blackmagic HyperDecks with your ATEM switcher and
setting the 'HyperDeck' configuration settings, refer to the 'HyperDeck control' section of
this manual.

Setting the HDMI Output Source

The HDMI output can have various sources routed to it. For example all video inputs, program,
preview, plus camera 1 direct for a low latency loop output when gaming.
HDMI output control menu on Mac OS
Changing Switcher Settings 51
