The quad HD outputs are assigned as follows:
‚ SDI Output A: Sub image 1
‚ SDI Output B: Sub image 2
‚ SDI Input Loop A: Sub image 3
‚ SDI Input Loop B: Sub image 4
Full Frame Ultra HD Image
Color Video
Clip
Aspect
Setup
Video>Setup
SDI Output Menu for Teranex AV only
This menu allows you select between single link or dual link outputs for your chosen output
format. Press the 'SDI output' button, or use the front panel knob to toggle between 'single link'
and 'dual link.'
‚ Single Link SDI outputs A and B support data rates from 270 Mb/s to 12Gb/s.
‚ Dual Link SDI supports 3G via 2x 1.5Gb/s, 6G via 2x 3Gb/s, and 12G via 2x 6Gb/s. SDI
outputs A and B facilitate dual-link output.
No Video
Setup
Input
Single Link
Dual Link
Video>Setup>SDI Output
3G SDI Output Menu for Teranex Express and Teranex AV
This menu lets you change the 3G-SDI output standard to maintain compatibility with
equipment that can only receive level A or level B 3G-SDI video.
No Video
Setup
Input
Level A
Level B
Video>Setup>3G SDI Output
Out A
Loop A
Quad HD Split Output
Proc No Video
Setup
Amp
Input
Single Link
Test
Patterns
Dual Link
Quad HD Split
Advanced
Setup>SDI Output
SDI
Output
3G SDI
Output
Quad SDI
Output
SDI
Output
3G SDI
Output
Quad SDI
Output
Out B
Loop B
SDI
Output
3G SDI
Output
Teranex Processor Settings 39 39
