Turn the knob to adjust. The range of adjustment is -12 to +12dB. Pressing the knob will return
the level to zero.
Video Main Menu
Audio
Noise
Reduction
Ancillary
Data
Main Menu>Audio Menu
Analog In Level for Teranex AV only
Teranex AV provides an input level selection menu that offers a choice between two audio
standards, such as SMPTE -20dBFS and EBU -18dBFS.
Video Main Menu
Audio
Noise
Reduction
Ancillary
Data
Main Menu>Audio Menu
Analog Input Menu
The 'audio setup' menu lets you select between the various analog audio input types.
The choices for Teranex 3D and Teranex AV are RCA Phono or XLR. The choices for
Teranex 2D are RCA Phono or DB25.
‚ RCA
Stereo RCA Phono connectors. Default for the Teranex 2D and 3D processors.
‚ DB25 for Teranex 2D only
Balanced analog audio input via the DB25 connector.
‚ XLR for Teranex 3D and Teranex AV only
Balanced analog audio input via the XLR connectors.
Video Main Menu
Audio
Noise
Reduction
Ancillary
Data
Main Menu>Audio
Analog
Audio Setup
In Level
RCA
DB25
Setup Menu>Analog Input
for Teranex 2D
System Output
Audio
Setup Mapping
Output Audio
Gain
Options
Audio
Delay
Setup
Audio Menu>Setup Menu
System
Output
Audio
Setup Mapping
Audio
Output
Options Gain
Audio
Delay
Setup
Audio Menu>Setup Menu
System Output
Audio
Setup
Mapping
Output Audio
Gain
Options
Audio
Delay
Setup
Audio Menu>Setup
Analog Analog
Audio Setup
Input In Level
RCA
XLR
Setup Menu>Analog Input
for Teranex 3D and Teranex AV
Input Analog
Setup
Mapping In Level
0.0
Setup Menu>Analog In Level
Audio Analog
Audio Setup
Meters In Level
SMPTE(-20dBFS)
EBU(-18dBFS)
Setup Menu>Analog In Level
Input
Mapping
Analog
Input
Teranex Processor Settings
Analog
Input
48 48
