‚ Set Timecode
The 'set timecode' menu options you will have are determined by the selection you
make in the 'start source' menu.
Prev Timecode
Start Value
Timecode
Input
Generator
Jam Sync
Set
n
Timecode
00:00:00:00
Setup
Jam Sync>Set Timecode
‚ Start Source = "Input"
If the 'start source' menu is set to 'input', the 'set timecode' menu will show 'input' as
the 'start value' for the timecode generator. When you press the 'start' button, the
generator will start looking for a timecode match to the 'jam sync' value you have
entered. When the match occurs, the generator will use that 'input' timecode as the
start value to generate free running output timecode.
‚ Start Source = "Start Value"
If the 'start source' menu is set to 'start value', the 'set timecode' menu will display
an eight-character register that allows the entry of a specific starting value for
the generator. When you press the 'start' button the generator will look for a
timecode match to the 'jam sync' value you have entered. When the match
occurs, the generator will use the start value you entered to generate free running
output timecode.
Video Index Menu
The 'video index' menu enables or disables reaction to video indexing signals that may be
embedded in your source video. The three video indexing modes that are supported are Active
Format Description, or AFD, Wide Screen Signaling, or WSS, and SMPTE RP186.
Index Reaction
If 'index reaction' is turned 'on', the Teranex processor will be set to react to incoming video
indexing signals. The processor will automatically scan for the presence of video index packets
and will react to them if found. AFD indexing takes precedence over the WSS, which takes
precedence over RP186.
‚ The default setting is 'off'.
NOTE The Teranex processor will not pass or insert WSS or RP186 codes. It will only
react to them if they are present on the input.
Closed
Ancillary Data
Caption
Timecode
Ancillary Data Menu>Video Index
Next
Start
Start
Source
Video Index
Index Reaction
Index
Reaction
On
Off
Video Index Menu>Index Reaction
AFD
Insertion
AFD
Inser Line
